Product Information

Hello everyone,
A lot of new versions has been released during the summer and we have compiled a list of the latest product news from iba. Registered users can download the new versions in our download area.

ibaHD-Server version v2.4.0.

With this new version of ibaHD-Server it is possible to generate offline events. The offline events can be used for calculating KPIs or other computed values based on existing dat files (in combination with the ibaDatCoordinator and ibaAnalyzer) and storing these KPIs as part of the message text of offline events. It is also possible to search special production situation in existing dat files and add an event for this situation in the event store of ibaHD-Server.

New features

1. ibaHD server supports offline events (e.g., events generated with ibaDatCoordinator).
2. Allow to write events to the same ibaHD store using different ibaDatCoordinator or ibaPDA clients
3. Added the possibility to set the displayed time span to the duration of an event in the event signal configuration menu.
4. ibaHD server backup scheduler: Add an option to clean backups older than a given timerange.
5. ibaHD manager: Display the software version of the connected clients in the connection tab.

ibaDatCoordinator version v2.2.5.

New features and improvements

The file-extract task has an option to extract to *.mat. This makes it possible to automate the generation of mat-files.
The server can be started without loading the previous configuration using the server status application. Now the service can be started even if the previous configuration got corrupted for some reason.

ibaCapture version v5.0.0.
ibaCapture-ScreenCam version v5.0.0.

New Features

Image overlays can be defined, for example to hide privacy sensitive areas of the video or to add lines for calibration or measurement.
ibaCapture now supports the H.265/HEVC video codec for compatible network cameras. Using H.265/HEVC allows to keep video quality high while reducing network bandwidth and storage requirements.

Information regarding licenses

With ibaCapture v5 WIBU licensing is introduced. Due to this, the following applies:
Existing ibaCapture v4 licenses with an EUP date of July 8th, 2020 or later will continue to work with ibaCapture v5.0.
Other existing licenses will need to be migrated to WIBU licenses. Contact your local iba support to start a migration request. Please include an ibaDongleViewer information file and an ibaCapture support file with your request.
All ibaCapture licenses from new orders will be delivered as WIBU licenses.

ibaVision version v2.0.0.

New Features

When using images from ibaCapture, the image timestamps can now also be transferred to the Halcon procedures as a tuple. This is possible in both online and offline processing modes.

Licensing

ibaVision v2 no longer supports existing licenses issued on MARX USB dongles. If you want to update to
ibaVision v2 from an older version, please contact your local iba support and ask for a license migration.

ibaPDA software release version v7.2.0.

Changed system requirements

The operating system Windows 2008 Server (x86) is no longer supported.
ibaPDA v7.2.0 now requires to have .NET framework 4.8 installed.

New available interfaces

The new SQL interface gives you read and write access to databases. With user-specific SQL queries you can read data from databases and map the results into signals which then can be used in the usual way for visualization, recording etc. within ibaPDA. Writing is also possible by user-specific SQL commands. In both SQL queries and commands you can use parameters as placeholders and dynamically paste signal values upon execution. The execution can be done cyclically or triggered.
The database types Oracle, SQL Server, PostgreSQL, MySQL and SAP HANA are supported and licensed separately (ibaPDA-Interface-Oracle/SQL-Server/PostgreSQL/MySQL/SAP-HANA , 31.001113/4/5/6/7). 8 modules can be used with each license whereat one SQL statement can be configured in each module. The number of modules can be increased by adding one or more one-step-up licenses (max. 32 modules).

The new DGM200E interface connects to the new DGM200-E gateway device provided by GE Power Conversion. The DGM200-E is connected to the fiber-optic based CC100 communication network on the one side and channels this link to Ethernet on the other side. This way you are able to connect to the CC100 network of the HPCi automation system via standard Ethernet cards in your ibaPDA system. With this interface in ibaPDA four network links to different DGM200-E devices can be used (ibaPDA-Interface-HPCI-DGM200E, 31.001009). The HPCi request function can also be used in combination with this interface.

ibaPDA can now record sound from an audio device (e.g. USB microphone) connected to the ibaPDA server PC (ibaPDA-Interface-Audio, 31.001101). The sound channel is recorded as analog signal and can be replayed using the Audio player function in ibaAnalyzer.

Main new features and improvements

The existing DB/Cloud timebased data store now supports many more database types. Identical to the SQL interface Oracle, SQL Server, PostgreSQL, MySQL and SAP HANA can be used. The DB/Cloud data store is used to write signals as time series data into a DB table. The table is created by ibaPDA with a layout that is determined by the settings of the data store profile used in the data store. With ibaAnalyzer v7.2.0 it will be possible to read the signal data via the SQL trend query function. With ibaDaVIS v2.7.0 it will be possible to visualize the signal data as well.
As for all streaming data stores the licensing is done per number of signals written without limitation of the number of used data stores. The database types are licensed separately (ibaPDA-Data-Store-Oracle-64/256/1024, 30.671020/1/2 || ibaPDA-Data-Store-SQL-Server-64/256/1024, 30.671030/1/2 || ibaPDA-Data-Store-PostgreSQL-64/256/1024, 30.671040/1/2 || ibaPDA-Data-Store-MySQL-64/256/1024, 30.671050/1/2 || ibaPDA-Data-Store-SAP-HANA-64/256/1024, 30.670141/2/3).

The MQTT timebased data store now offers the possibility to use a file-based data buffering in case the connection to the broker is lost. This way a large amount of data can be buffered for long time ranges.

A new trigger type is available for the Kafka/MQTT/MindSphere timebased data store: The trigger “One sample on change…” allows you to choose one signal which is monitored for value changes. Each time the value changes one record is written by the data store.

For anomaly detection in cyclic and rotating processes the new add on ibaInCycle (ibaInCycle, 30.681215) is introduced. Any signal with repeating cyclic behavior can be monitored with ibaInCycle. Two module types can be used: The expert module offers an individual analysis of the cycles. The auto adapting module provides a self-learning functionality taking into account process conditions. For visualizing the results the new Cycle view and Circle view are available.

Various new features are available in ibaQPanel: E.g. for the button and label control new settings like border size, border color, transparent background etc. have been added. The file picker is replaced by a file selector with extended functionality and in the various trend graphs the signal visibility can be controlled by a digital signal.

A decoder module was added for our EtherCAT bus monitor ibaBM-eCAT. This module type is useful when you want to record a large number of digital signals that are arranged in signals of the data type WORD.

The ibaPDA installer can now automatically search for dongle license updates. When activating this option in the installer you can specify a directory which is checked for license updates belonging to your dongle number during the installation. This way license and version updates can be done in one step without additional down times of ibaPDA.

Several features have been added to the OPC UA client interface and the OPC UA server. The most mentionable is the support for user defined information models. If the standard OPC UA symbol tree provided by ibaPDA is not sufficient, you can import your own OPC UA information model and map ibaPDA signals into it.

It is now possible to change the language of the ibaPDA service via the ibaPDA server status application. Before the language was always determined by the regional settings of the ibaPDA server PC.

Starting with ibaPDA v7.2.0 there will no longer be a separate Language Pack available. Now all language resources are integrated in the regular ibaPDA installer. Older language packs that might be installed on your PC are automatically uninstalled.

For full reference on other included new features, improvements and bugfixes please download this new version and check the included version history document.

If you have any questions or concerns please contact us at info@begner.com
