ibaPDA-Interface-TwinCAT-Xplorer

Communication interface - Data acquiring and recording with free symbol selection from Beckhoff PLC systems via standard communication interfaces, without additional communication hardware

Technical Data:

Interface extension for access to Beckhoff- PLC's with Beckhoff-ADS-Protocol

Supports TwinCAT-Version 2 and 3

Data acquiring via TCP/IP

Signal selection via symbolic

max number of connections / modules: 16

Remark:

Requires an ibaPDA basic license

Please provide with your order the dongle number of your existing ibaPDA system. The dongle number is required to generate a license upgrade for your system.

If there are more than 16 connections / modules required, the interface can be extended with additional 16 connections / modules with the license "one-step-up-Interface-TwinCAT-Xplorer". This license extension can be used 14 times per interface and allows in total 240 connections / modules per interface.

Status:available
