Picture of ibaPDA-Interface-Modbus-TCP-Client-16

ibaPDA-Interface-Modbus-TCP-Client-16

ibaPDA Interface: Modbus TCP/IP Client-16

(HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Manufacturer: iba AG
SKU: 31.001024

Communication interface; Modbus Client 16 - PDA Modbus TCP/IP Interface for communication with systems and devices which supports Modbus Server functionality.

Technical Data:

  • PDA driver decoding for Modbus over TCP/IP
  • Client functionality:
    - Active communication partner
    - Initiates the Modbus communication
    - Requests data from a Modbus server
  • Useable for Devices with Modbus TCP/IP Server functionality and Modbus serial devices behind a Modbus TCP/IP to serial Gateway
  • The following Modbus register can be read (supported Modbus Function codes):
    - Coils (Modbus Function code 1)
    - Discrete Inputs (Modbus Function code 2)
    - Holding registers (Modbus Function code 3)
    - Input registers (Modbus Function code 4)
  • The type of function codes to choose depends on the Modbus server.
  • Number of connections/modules: 16

    •  Remarks:
  • Requires an ibaPDA base license
  • Only available for WIBU licensing
  • Please provide to us the number of the existing license container or license ticket within your order that we can prepare the license extension
  • If there are more than 16 communication connections (modules) required, the interface can be extended with additional 16 interfaces (modules) with the license "one-step-up- Interface-Modbus over TCPIP - Client-16". This license extension can be used 15 times per interface and allows in total 256 connections (modules) per interface.
