ibaLogic-V5 Timing Diagnostics

Graphical online signal calculation and processing
(HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)

Manufacturer: iba-ag

SKU: 32.500005

Extended Diagnostics - ibaLogic V5 Timing Diagnostics

Technical Data:

The ibaLogic V5 Timing Diagnostics is able to record either the task or the program timing of individual ibaLogic PMACs = Runtimes within dat- files

The recording itself is carried out always on the computer where the tool is executed. The tool is automatically installed with ibaLogic.

Always the latest status information are being recorded (idle, run, break) and due to this the computer execution time per task in µs

For each task it will be recorded:
- one analog signal (idle = 0, run = 1, break = -1)
- one digital signal (idle = 0, run or break = 1)
---
With the digital signal a smarter and faster access to the displayed timing is possible by using the double-click feature of the ibaAnalyzer

Special Remark:

This tool requires a license that can be used
- either with an existing dongle
- or with an extra dongle
To provide the way of license must be requested by the license ordering!

To record an ibaLogic-PMAC within a PADU-S-IT2x16 requires always a PC with the license dongle (usb-dongle)

With one license it is possible to record a single data store for each existing ibaLogic PMACs ( Runtimes) doesn't matter where the PMAC is executed, either on a PC or in an ibaPADU-S- IT2x16. For analysis ibaAnalyser is required.

Status:available
