ibaCapture-Server-1440fps

Basic License for Video Capturing; Record up to 1440 fps - Server license for video recording

• The number of cameras is limited by the total allowed framerate of the server license (max. 64 cameras total)

Technical Data:

• Capture Server base license for video recording from cameras and virtual iba cameras
• Video- and data capture:
  - Synchronized process data acquisition between ibaCapture and ibaPDA servers
  - Analysis and video display in ibaAnalyzer
• Includes one Interface "ibaCapture-Interface-PDA" for synchronization with one ibaPDA Server. For every other ibaPDA server another "ibaCapture-Interface-PDA" license is required
• Requires additional interface licenses for the desired cameras:
  - ibaCapture-1CAM-REC or
  - ibaCapture-1CAM-DISP or
  - ibaCapture-1CAM-VIRT or
  - ibaCapture-1CAM-GigE
• Includes 144 client Live-Streams for video live views. If necessary, the amount of allowed streams can be extended with "ibaCapture-Live-Stream Add-On" licenses. Replaying stored video is not limited.
• Supported camera types:
  - Analog cameras (PAL/NTSC) either via framegrabber-board (PCIe) or analog-IP-converter (e.g. AXIS P7214)
  - IP-cameras (ONVIF, AXIS), if mpeg4, h264 or h265 video codecs are supported by the camera
  - GigE-Vision cameras (GenICam) with supported Network Interface Controller
  For usage the license for a supported GigE-Vision SDK is required (e.g. Pleora eBUS Runtime)
  - HMI-camera (virtual) with ibaCapture-HMI (at least v4.0.0)
  - MachineVision-output (virtual camera) with ibaVision

Remarks:

• Usable under these operating systems:
  Windows 7, Windows 10, Windows Server 2008 (R2), Windows Server 2012 (R2), Windows Server 2016
• When using PCIe framegrabber boards in PCs from 3rd party suppliers there might be some restrictions
• Enabled with USB dongle or soft license
• Contains software maintenance and support after the purchase for 2 years. Afterwards a software maintenance and support contract is required.
